Low Speed Vehicle Lithium Battery
CERAMAX provides high performance Lithium-ion batteries for low speed propulsion applications such as golf cart, mobility scooter, electric boat, tour car, recreational vehicle and etc. Based on a proven record of quality and safety, CERAMAX supplies battery systems for users from worldwide countries. Along with the advanced Battery Management System, valuable battery telemetry and status code information is provided for use in remote monitoring and battery diagnostics.
1. Easy installation
2. Super smart BMS
3. Robust communication
4. High security
5. Long cycle life
6. High discharge rate
7. Maintenance free
FUNCTIONAL SPECIFICATIONS | |
Nominal Voltage | 24V/48V/Customizable |
Ampere-hour Capacity | 60Ah/100Ah/Customizable |
Watthour Capacity | 1.536kWh/3.072kWh |
Impedance (50% SOC, 1kHz) | <100mΩ |
Cycles @ 80% DOD | >3500 |
DISCHARGE SPECIFICATIONS | |
Continuous Discharge Current | 100A |
Peak Discharge Current | 240A – 15 sec |
Self-Discharge per Month @ 25°C in OFF mode | 2.80% |
CHARGE SPECIFICATIONS | |
Continuous Charge Current | ≤ 60A |
Recommended Charge Voltage | 27.6V/55.2V |
ENVIRONMENTAL SPECIFICATIONS | |
Charge Temperature | 0°C to 55°C |
Discharge Temperature | -30°C to 65°C |
Operating Humidity | <90% RH |
Storage Temperature | -20°C to 35°C |
Storage Humidity | 25 to 85% RH |
