CM-48280 Wall-mounted Lithium Battery
CERAMAX Wall-mounted 48280 Lithium Battery has compact design, LCD screen,convenient setting buttons, Bluetooth monitor on your smartphones, and cables&accessories ready for installation. With more than 6000 times deep cycle, up to 80% DOD and phosphate battery Cell, CERAMAX Battery has won global approval!
CERAMAX Lithium Ion Wall-mounted Batteries are widely used in Solar Systems for residential and commercial system.
Work Mode Demonstration
Products Advantage
1.High Safety
（Over charge, over discharge and over temperature protection)
2.Communication
(RS485, RS232, CAN)
3.Long Cycle Life ≥6000 Times
4.Smart
(Each module is equipped with an independent BMS system)
5.Certifications
( CE, MSDS, UN38.3, IEC, TUV)
6.Modular
(Compact size and light weight)
Model | CM48280 |
Battery Type | LFP |
Nominal Voltage | 48V |
Rated Voltage | 51.2V |
Capacity | 280Ah |
Working Voltage Range | 40-58.4V |
Recommend Charge/Discharge Current | 140A |
The Charge/Discharge Ratio | 0.5C |
Rated Energy(KWh) | 14.336 |
DOD | 80% |
Life time | ≥ 6000 cycles(At 80% DOD at 25 deg C) |
Working Temperature | Charge: 0-60℃ Discharge: -10- 60℃ |
Humidity | 5% – 95% |
IP protection Rating | IP56 |
Communication Mode | CAN, RS232, RS485 |
